soya chunks packing machine

Suitable for different granule groducts, such as beens, chips, frozen food, pet food , hardware etc All kinds of grain material, sheet material, strip material and abnormity material which such as candy, melon seeds, chips,peanut, nuts, preserved fruit, jelly, biscuit, confect, currant, almond, chocolate, filbert, corn, Potato Crisps,pet foodstuff, dilatant foodstuff, hardware and plastic can be weighed by the ration.



CONTACT US

Specification (With the product size selection models) :

Model KL-420A KL-520A KL-720A
Film Width Max.420mm Max.520mm Max.720mm
Bag Length 80-300mm 80-350mm 100-450mm
Bag Width 60-200mm 100-250mm 180-350mm
Roll Diameter Max.320mm Max.320mm Max.320mm
Film Thickness 0.04-0.12mm 0.04-0.12mm 0.04-0.12mm
Measuring Range 150-1500ml 2000ml 4000ml
Packing Speed 5-60bag/min 5-60bag/min 5-55bag/min
Power Supply 220V 50/60Hz 2KW 220V 50/60Hz 3KW 220V 50/60Hz 3KW
Machine Size (L)1217*(W)1015*(H)1343mm (L)1488*(W)1080*(H)1490mm (L)1780*(W)1350*(H)2050mm
Machine Weight About 650kg About 680kg About 750kg
Option Device

Two synchronous belt device, air filling device, angle fold device,

automatic rectifying device, hole-punching device, link bag device.



Optional device for your choice:

1. Date Printer

2. Hole Punching Device(Hand hole, Round hole, Euro hole)

3. Linking bag control device

4. Air-filling Device

5. Air Exhaust Device

6. Easy-Tear Device

7. Nitrogen inflation device

8. Gusset Bag
